Easy to install and discreet to integrate, this shutter is ideal for renovation.
The ID4 range is accessible to both professionals and individuals .
With a height of 13 or 16.5 cm, this roller shutter lets in maximum light. The housing has no visible screws, for even more discreet integration.
The solar panel is perfectly integrated into the Bubendorff shutter box for an aesthetic and discreet finish.
The Mono ID4 can be installed quickly, without electrical connection thanks to its integrated battery (excluding the motor).
Optimize natural ventilation and control light with the adjustable slat option: the perfect combination of blackout, security and sunlight management.
Unlike the Tradi ID3 model, the Mono ID4 is installed exclusively with external winding, under lintel or on facade.
The shutter comes with a protective aluminum housing.
images/v5/BUBENDORFF/09-07-25_tablier_368-OR-MOUST-MONO-ID4.jpg?1752073463965" style="border-radius: 5px;" />
Installation No. 3 is the most common installation of a roller shutter, with the aluminum curtain that goes down in front of your window and the box that goes outside.
(Winding outwards).
The tracks are pre-drilled at the bottom of the track, so that they can be fixed to the right and left in your window frames.
Installation No. 4 allows you to fix your shutter to your facade.
(Winding outwards).
The tracks are pre-drilled on the front, so they can be fixed into your facade.
The integrated mosquito net is located at the rear of the shutter box, thus offering a simplified maintenance system with easy access.
Option available in layout #3 with 130 and 165 mm boxes.
Recommended measures:
Manufacturing width between 490 and 1600 mm
Manufacturing height between 430 and 2672 mm
The best of roller shutter and adjustable sunshade
Not available in inner wrap #1
- DP368 apron = 1500 mm
- Adjustable apron = 1330 mm
- DP368 apron = 1500 mm
- Adjustable apron = 1330 mm
Not available in location no. 1
Not available in location no. 1
Class II motor with 4 wires (phase, neutral, up and down) without earth wire.
Delivered without inverter
Allows connection of a wired switch for roller shutters (not included)
In the event of a power outage, the motor only operates with its transmitter
Class II motor with 4 wires (phase, neutral, up and down) without earth wire.
Delivered without inverter
Allows connection of a wired switch for roller shutters.
In the event of a power outage, the motor only operates with its transmitter
![Mono ID4 roller shutter - Bubendorff, : Bubendorff Universal Radio Motor + Remote Control (wire on the right) [RU]](https://lacentrale-eco.com/images/thumbnails/300/300/variant_image/44/RU-droite.jpg "Mono ID4 roller shutter - Bubendorff, : Bubendorff Universal Radio Motor + Remote Control (wire on the right) [RU]")
Bubendorff mains motor, radio controlled, supplied with its factory-paired transmitter.
Low power consumption.
Compatible with Bubendorff and Zigbee 3.0 systems.
Possibility of automatic control of the shutter in accordance with RE2020.
2-wire cable (usable length of 1.5 m)
![Mono ID4 roller shutter - Bubendorff, : Bubendorff Universal Radio Motor + Remote Control (wire on the left) [RU]](https://lacentrale-eco.com/images/thumbnails/300/300/variant_image/44/RU-gauche.jpg "Mono ID4 roller shutter - Bubendorff, : Bubendorff Universal Radio Motor + Remote Control (wire on the left) [RU]")
Bubendorff mains motor, radio controlled, supplied with its factory-paired transmitter.
Low power consumption.
Compatible with Bubendorff and Zigbee 3.0 systems.
Possibility of automatic control of the shutter in accordance with RE2020.
2-wire cable (usable length of 1.5 m)
Bubendorff motor with solar charging and radio control, autonomous for 30 days without sun.
Supplied with a Bubendorff transmitter.
The solar collector (PV panel) must absolutely:
PV panel integrated into the external winding box (No. 2-3-4)
PV panel mounted on the surface of the internal winding box (No. 1)
The photovoltaic panel cable exit is always on the right in interior view.
It has an intelligent piloting system.
Note: the solar panel must be aligned with the plane of the facade
Bubendorff motor with solar charging and radio control, autonomous for 30 days without sun.
Supplied with a Bubendorff transmitter.
The solar collector (PV panel) must absolutely:
Sites with heavy snowfall: the PV panel must be positioned vertically and on the facade.
Control function: the PV panel must be positioned close to the shutter, on the same facade and without shading on the panel.
This color is not available for the adjustable apron.
This color is not available for the adjustable apron.
This color is not available for the adjustable apron.
This color is not available for the adjustable apron.
∆R = 0.25 m².K/W
This shade is only available for blades with a tinted outer face and a low-emissivity aluminum inner face.
The motor comes with its basic remote control, but no additional remote control is included.
Product reference: 229026 - for ID2, R, RG motors (radio protocol type)
4-channel remote control, including 1 with clock - H4C - Bubendorff
The IDiamant with Netatmo module allows you to open and close your shutters remotely, via your smartphone.
The Bubendorff CLIMAT+ control automatically manages your shutters for optimal comfort and energy savings.
It takes into account indoor and outdoor temperature, as well as sunlight for maximum efficiency.
It can control up to 30 roller shutters simultaneously.
The Somfy Inis wired switch allows you to easily control your roller shutters for simple and reliable everyday use.
It offers intuitive control thanks to its up, down and stop buttons, ensuring precise control of your equipment.
Compatible with most wired motors, it can control a roller shutter or a group of shutters depending on the installation.
