Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff

Write review
TRADI-ID+-DP368-413
Save 23%
Rolling shutter: -23% discount (27% from 1200€, 30% from 2400€)
10 Days
ManufacturerBubendorff OriginFrance
TRADI ID+ roller shutter for invisible installation in a titan box The Trad component from Bubendorff Small footprint which allows it to be adapted to all joinery chests Additional thermal resistance of the apron: ΔR = 0.15 m².K/W for aprons DP368, DP413 Thermal performance adapted...
From:
332€64
432€00
Price (without VAT) = 277€20

3 weeks
bubendorff-volet-roulant-store-telecommande-filaire-radio-volet
Add to favourites Print product details (pdf)
Validation, monitoring and support
Free delivery in France from 2400€ttc
Payment: 4x free of charge
Delivery method
  • Back to top
  • Description
  • Documentation
  • Options details
  • Features
  • Customer reviews
Description

TRADI ID+ roller shutter for invisible installation in a titan box

The Trad component from Bubendorff

  • Small footprint which allows it to be adapted to all joinery chests
  • Additional thermal resistance of the apron: ΔR = 0.15 m².K/W for aprons DP368, DP413
  • Thermal performance adapted to RE 2020.
  • A product designed down to the smallest detail
  • Stainless steel fastening system, height adjustable
  • Slightly curved guide rail shape and optimized size
  • Excellent wind resistance of the curtains thanks to a patented hooking system behind the slides
  • Radio Solar or "hybrid" motorization
  • Home automation easy to install with the iDiamant

A width from XS to XXL

  • From a minimum width of 44 cm
  • 13 mm thick double-walled aluminum slat to support large widths up to 4500 mm
  • Winding of the blades optimized for installation in standard size boxes

TRADI ID + roller shutter: Designed to last

  • Aluminum aprons offering enhanced resistance to corrosive environments across the entire color chart. All the powder coated frames of the standard and extended color charts are textured and classified High Durability according to the ISO 16474-2:2013 standard.
  • Aluminum (DP368, DP413) double wall profile with CFC-free foam insulation
  • Steel flange with cataphoresis coating for resistance to salt spray of 480 hours
  • Blade tips to reduce friction
  • Tested to 30,000 cycles. This is twice as much as the NF standard which stops at 14,000 cycles.
  • After-sales service for 20 years
  • End slat in extruded aluminum

Technical characteristics

  • Double-walled aluminum apron equipped with slat ends with storm hooks (depending on dimensions) and automatic locks
  • All the slats of Bubendorff shutters are perforated, to allow the light to be dosed at will, and equipped with noise-reducing end caps.

Find the pdf with all the information on the TRADI ID+

Datasheet (for ID+ and iD3)

Installation instructions

Advantages of the traditional Bubendorff ID+ roller shutter

  • Completely invisible, integrated under the facade cladding, it can be installed both in new construction in tunnel boxes, and in renovation in existing joinery boxes.
  • A large choice of slats to cover all sizes of openings. This shutter is up to 4.5 meters wide

Insulated aluminum slats tradi ID+ roller shutter

Size of roller shutters for trunk

h = existing deck height

Windings made with an octagonal axis of 60 mm in diameter.

Bubendorff max size 368

The DP368 apron is compatible with any titan box regardless of size.

We find this width of aluminum slats for the smallest dimensions, with a maximum width of 3000mm.

:block;">
max size bubendorff 408

The DP408 apron is compatible with any titan box regardless of size.

Max size bubendorff 413

The DP413 apron can be embedded in a box if it does not exceed 2500 mm in height. This type of aluminum slats can go over a maximum width of 4500 mm.

reinforcement on box C bubendorff

Traditional titan reinforcement

The reinforcement will be automatically added to the price of the titan C 28/28 box if the width exceeds 1700 mm

Documentation

Bubendorff product and order form (download)

Technical details of the Tradi ID+ shutter (download)

Options Details

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, Shutter alone or with a box : Roller shutter on one side and titan C 28/28 box on the other (Lmx3400 x Hmax 2500)
Shutter alone or with a box
Roller shutter on one side and titan C 28/28 box on the other (Lmx3400 x Hmax 2500)

box C28 with fibreaglo

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, Shutter alone or with a box : Roller shutter on one side and box titan F 28/28 on the other (Lmx3400 x Hmax 2500)
Shutter alone or with a box
Roller shutter on one side and box titan F 28/28 on the other (Lmx3400 x Hmax 2500)

You will receive your shutters on one side, and the boxes on the other. This will make it easier for you to install the boxes because there won't be the shutters in there. And then you will install the shutters, once the facade is finished.

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, : Moteur Filaire Bubendorff avec inverseur Hager [MI]
Which motorisation do you want?
Moteur Filaire Bubendorff avec inverseur Hager [MI]

Moteur Bubendorff secteur, à commande filaire, compatible avec tous les inverseurs (type volet roulant) du marché

Notice moteur MI (download)

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, : Bubendorff + remote control [R]
Which motorisation do you want?
Bubendorff + remote control [R]

Bubendorff mains motor, radio-controlled, delivered with its factory-paired transmitter

Notice moteur R (download)

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, : Bubendorff Hybrid 2 wires + transmitter [HY] - Lmin 525 - DP368
Which motorisation do you want?
Bubendorff Hybrid 2 wires + transmitter [HY] - Lmin 525 - DP368

Câble 2 fils, longueur utile 1 m.

Moteur Bubendorff à recharge secteur, à commande radio ou filaire, fonctionnant pendant 7 jours en cas de coupure de courant

Notice moteur HY (download)

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, : Bubendorff Hybrid 4 wires + transmitter [MH] - Lmin 525 - DP368
Which motorisation do you want?
Bubendorff Hybrid 4 wires + transmitter [MH] - Lmin 525 - DP368

Câble 4 fils, longueur utile 1 m.

Moteur Bubendorff à recharge secteur, à commande radio ou filaire, fonctionnant pendant 7 jours en cas de coupure de courant

Notice moteur MH (download)

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, : Bubendorff Solar [SO] - Lmin 525 - DP368
Which motorisation do you want?
Bubendorff Solar [SO] - Lmin 525 - DP368

Moteur Bubendorff à recharge solaire et commande radio, autonome 30 jours sans soleil.

Le capteur solaire (panneau PV) doit impérativement :
• être positionné à l’extérieur de l’habitat,
• pouvoir recevoir un éclairage direct
• ne doit pas être masqué par tout objet (incluant par exemple : vitrage, volet battant, balcon, arbre, haie dense, ...)

Sites de fort enneigement : positionner obligatoirement le panneau PV verticalement et en façade.

Fonction Pilotage : le panneau PV doit être positionné à proximité du volet, sur la même façade et sans ombrage sur le panneau.

Notice moteur SO (download)

Manoeuvre par treuil Lmax3000 x Hmax2500 - DP368 [XT45]
Which motorisation do you want?
Manoeuvre par treuil Lmax3000 x Hmax2500 - DP368 [XT45]

Manoeuvre par treuil - lame DP368 avec sortie de caisson en sous-face

Tablier alu DP413
Aluminium curtain
Aluminium door leaf DP413

Coulisse MG

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, Additional remote control: ID2 radio clock for Bubendorff ID2 roller shutter
Additional remote control
ID2 radio clock for Bubendorff ID2 roller shutter

Product number: 229026 - for ID2, R, RG motor (radio protocol type)

Notice (download)

Built-in TRADI ID+ roller shutter with insulated aluminum slat 368/408/413 - Bubendorff, Additional remote control: iDiamant module with NETATMO - Bubendorff
Additional remote control
iDiamant module with NETATMO - Bubendorff

The IDiamant with Netatmo module allows the remote opening and closing of shutters, via your smartphone.

Notice (download)
