Documentation
Options Details
Type of glazing
Double glazing [9T] Standard
Technical glazing data:
Standard double glazing (9T) without WD
• UG value: 1.0
• UW value: 1.5
• G value in %: 40
• Acoustic insulation class in DB: 29
• Airtightness class: 3
• SOLAIRE FAUTOR SW: 0.33
Standard double glazing (9T) with WD
• UG value: 1.0
• UW value: 1.4
• G value in %: 40
• Acoustic insulation class in DB: 29
• Airtightness class: 3
• SOLAIRE FAUTOR SW: 0.29
Type of glazing
Double glazing [8g] Premium
Technical glazing data:
Premium double glazing (8g) without WD
• UG value: 1.0
• UW value: 1.4
• G value in %: 29
• Acoustic insulation class in DB: 29
• Airtightness class: 3
• SOLAIRE FAUTOR SW: 0.24
Premium double glazing (8g) with WD
• UG value: 1.0
• UW value: 1.3
• G value in %: 29
• Acoustic insulation class in DB: 29
• Airtightness class: 3
• SOLAIRE FAUTOR SW: 0.21
Outdoor finish
Standard - R703 lacquered aluminum
Outdoor finish
Copper
Outdoor finish
Zinc - titanium
Outdoor finish
RAL to be specified when ordering
We recommend clear colors such as RAL 9016 (white signaling) or RAL 9010 (pure white) to avoid excessively capturing the heat of the sun.
Features
Roof window connection
Designo
Manufacturer
Roto
Origin
Germany
Guarantee
- 15 ans
ROTO DESIGNO dimensions
- 11/11 - 114 x 118 cm ,
- 11/14 - 114 x 140 cm ,
- 13/9 - 134 x 98 cm ,
- 5/7 - 54 x 78 cm ,
- 5/9 - 54 x 98 cm ,
- 7/11 - 74 x 118 cm ,
- 7/14 - 74 x 140 cm ,
- 7/9 - 74 x 98 cm ,
- 9/11 - 94 x 118 cm ,
- 9/14 - 94 x 140 cm
Window type
PVC
Control system
Manual (M)
