Options Details
![Fenêtre Roto Designo R7 en PVC, Type of glazing: Double glazing [9T] Standard](https://lacentrale-eco.com/images/thumbnails/300/300/variant_image/28/double-vitrage-9T.jpg "Fenêtre Roto Designo R7 en PVC, Type of glazing: Double glazing [9T] Standard")
Type of glazing
Double glazing [9T] Standard
Technical glazing data:
Standard double glazing (9T) without WD
• UG value: 1.0
• UW value: 1.5
• G value in %: 40
• Acoustic insulation class in DB: 29
• Airtightness class: 3
• SOLAIRE FAUTOR SW: 0.33
Standard double glazing (9T) with WD
• UG value: 1.0
• UW value: 1.4
• G value in %: 40
• Acoustic insulation class in DB: 29
• Airtightness class: 3
• SOLAIRE FAUTOR SW: 0.29
![Fenêtre Roto Designo R7 en PVC, Type of glazing: Double glazing [8g] Premium](https://lacentrale-eco.com/images/thumbnails/300/300/variant_image/28/double-vitrage-8G.jpg "Fenêtre Roto Designo R7 en PVC, Type of glazing: Double glazing [8g] Premium")
Type of glazing
Double glazing [8g] Premium
Technical glazing data:
Premium double glazing (8g) without WD
• UG value: 1.0
• UW value: 1.4
• G value in %: 29
• Acoustic insulation class in DB: 29
• Airtightness class: 3
• SOLAIRE FAUTOR SW: 0.24
Premium double glazing (8g) with WD
• UG value: 1.0
• UW value: 1.3
• G value in %: 29
• Acoustic insulation class in DB: 29
• Airtightness class: 3
• SOLAIRE FAUTOR SW: 0.21
Type of fittings
Ardoise built -in fittings
Ardoise recessed fitted fittings with or without insulating block
Outdoor finish
Standard - R703 lacquered aluminum
Outdoor finish
Copper
Outdoor finish
Zinc - titanium
Outdoor finish
RAL to be specified when ordering
We recommend clear colors such as RAL 9016 (white signaling) or RAL 9010 (pure white) to avoid excessively capturing the heat of the sun.
Features
Manufacturer
Roto
Origin
Germany
Guarantee
- 15 ans
Roof window connection
Designo
ROTO DESIGNO dimensions
- 11/11 - 114 x 118 cm ,
- 11/14 - 114 x 140 cm ,
- 13/14 - 134 x 140 cm ,
- 13/9 - 134 x 98 cm ,
- 5/7 - 54 x 78 cm ,
- 5/9 - 54 x 98 cm ,
- 7/14 - 74 x 140 cm ,
- 7/9 - 74 x 98 cm or 78 x 98 cm ,
- 9/11 - 94 x 118 cm
Window type
PVC
Control system
- Manual (M)
DOORS AND WINDOWS
Glazing thickness
- Double vitrage ,
- Double vitrage premium
Reviews
No reviews found
Video gallery
Pose Roto Designo R7 - Version longue
Pose Roto Designo R7
Consignes de nettoyage
Présentation - Fenêtres de toit Roto Designo R7
